Cloud Monitoring

1.Overview of Cloud Monitoring

Cloud Monitoring is an automated camera system that provides daytime hemispheric sky images that are used to measure the proportion of the sky view that is covered by clouds.With the development of natural science, cloud observations continue to be valued.In the early days, professionals needed to observe the clouds through the naked eye and manually record the observation results.The accuracy of the observation results varies greatly depending on the observer's experience and technical level.In order to reduce labor costs, improve observation accuracy, and achieve unattended automatic observation of the sky around the clock, Cloud Monitoring has gradually replaced manual observation.Cloud Monitoring has combined with the application of machine deep learning algorithms to greatly improve the degree of automated observation of the cloud and enhance people's research and utilization of solar energy resources.

2.Cloud Monitoring function description

FT-TK2 Cloud Monitoring is a new generation of fully automatic, full-color sky imaging equipment independently developed by our company.The device has a 220° super large visual angle.Through IOT intelligent network technology, the image information and weather data obtained in real time can be transmitted to the back-end computing center.After the data is processed by quality control and AI image recognition model, the real-time image data, cloud coverage, light transmittance and additional weather data will be provided to the user terminal in various forms.

3.Cloud Monitoring hardware specifications and parameters

Image sensor: 1/2.7" Progressive Scan CMOS 5 million pixels (default 2 million output, 2 million, 3 million, 5 million three-speed can be remotely adjusted through the cloud)

Minimum illumination: Color: 0.01Lux F1.2

Image signal-to-noise ratio: ≥50dB (AGC OFF)

Wide dynamic range: ≥80dB

Maximum image resolution: 2592×1944

Support image resolution: 2592×1944/2560×1920/2048×1536/1080P(1920×1080)

Lens viewing angle: about 220° full fisheye

Focal length: 2.8mm

Light-through aperture (Aperture): F1.8

Input voltage range: 11~13.5VDC, standard input voltage: 12VDC (supports two ways of supplying adapter and solar energy)

The power consumption of the whole machine does not exceed 10W, and the average power consumption is 6.5W.

Network communication method: 4G

Temperature and humidity sensor:

Temperature: Sensor accuracy ±0.3℃, the accuracy applies to range 0℃~65℃, and the use range -20℃~55℃

Humidity: Sensor accuracy ±3%RH, accuracy applies to range 10%RH~90%RH, use range 0%RH~100%RH

Atmospheric pressure sensor: sensor accuracy ±1hpa range 300hpa ~ 1100hpa

Working temperature -20℃~55℃

button:

Power button: Power on/off

Setting key: In the running state of the device, wait for a period of time after pressing, the device enters Bluetooth mode, which is used for user binding and resetting the network.

Indicator light:

Turn on: The yellow light will not be on for more than 5 seconds

Bluetooth mode: red and green light, flashing intermittently every second

Operation status: 4G network mode, green light flashes once every 10s

No network available: red light flashes for 30 seconds

Weather data and image sampling frequency can be adjusted, uploaded once every 1 minute soon

Product Material: PC

External dimensions (length, width and height): 305x175x330mm

Waterproof grade: IP55

Product weight: 2kg

Installation method: vertical pole

Single set configuration list
