Rodent monitoring system

1.Introduction to Rodent monitoring system Products

Rodent monitoring system uses digital devices and wireless communications to monitor and capture rodents, helping us identify key areas of rodent infestation.Rodent monitoring system enables long-term, efficient and accurate monitoring of rat situation and rat density distribution in the region.Based on artificial intelligence algorithms, big data, Internet of Things and other technologies, through terminal recognition and shooting, biological intelligence recognition technology, identification analysis and recording, remote data transmission, data sorting and analysis, and research on the automatic inducing and control technology of rat-like intelligent cycles.

2.Technical parameters of Rodent monitoring system

1.The main components of the equipment: mouse catching channel, information collection module, lure module, central control module, power supply module, rat killing module (prevention and control type), mouse storage module (scientific research type), automatic release module (circulating type)

2.Data collection type: Image pixels: 2 million-20 million (can be customized according to actual conditions)

3.All-round trapping, automatic switch trapping port

4.Storage format: JPEG

5.Induce delivery: Automatic reset of intelligent delivery (cyclicity; control delivery time and quantity)

6.Real-time data analysis: 365*24 hours real-time data collection, real-time understanding of the density and types of harmful rats, analyze the information of rat conditions, and make predictions of rat conditions

7.Visual parameters: mouse type, quantity, weight, image, activity rhythm, etc.

8.Historical data display: Supports historical data import system analysis and visual display

9.Data interface: USB2.0/USB3.0

10.Communication frequency band: 7-mode full network access

11.Communication mode: 2G/3G/4G (expandable)

12.Operation strategy: Remote control

13.Working mode: timed wake-up, infrared combination wake-up 14.Parameter settings: support remote password protection and remote fault diagnosis

15.Working mode: timed wake-up, infrared combination wake-up

16.Parameter settings: Support remote password protection and remote troubleshooting

17.Detection functions: infrared detection, image detection, weighing detection (cyclic type)

18.Protection level: IP67

19.MTTR: ≤30min

20.MTBF:＞2000Hour

21.Usage environment: It can be installed and used in most environments

22.Standby time: solar power supply

23.Working voltage: 12V

24.Operating current: 5A

25.Working temperature: -15℃~60℃

26.Intelligent monitoring and control of rat damage warning and forecast, remote cloud management.
