Mine Explosion-proof Dust Meter

1.Mine Explosion-proof Dust Meter Product Overview

Mine Explosion-proof Dust Meter provides mines with real-time results during dust surveys and is suitable for use in coal mines where explosion proofing is required.Mine Explosion-proof Dust Meter (hereinafter referred to as the measuring instrument) is an instrument used to measure the concentration of floating dust in ambient air based on the principle of infrared light absorption.The instrument is based on the technical conditions of the MT163-1997 "General Technical Conditions of Direct-Read Dust Concentration Measuring Instruments" and the technical conditions of the Q/320582YLA013-2016 "CCZ1000 Direct-Read Dust Concentration Measuring Instruments" and the ExibI grade (intrinsically safe) explosion-proof dust concentration measurement instrument in the GB3836-2010 standard.The separation efficiency of the respiratory separation device of this instrument fully complies with the internationally recognized "BMRC" curve requirements, and can accurately and timely reflect the quality of respiratory dust inhaled by dust collectors and the pollution status of dust in different dust workplaces, providing reliable data for accurately evaluating the hygiene status of the workplace.The instrument is suitable for underground coal mines and other workplaces containing explosion hazardous gases.

The instrument has compact structure, simple operation, large load and negative pressure capability, automatic timing sampling, stable flow, full Chinese LCD display, and easy portability.

2.Mine Explosion-proof Dust Meter technical indicators

1.Dust concentration measurement range: 0.01mg/m3～1000mg/m3

2.Relative error of dust concentration measurement: ±15%

3.Relative stability error: ±2.5%

4.Sampling flow: 2.0L/min

5.Sampling flow error: ≤2.5%

6.Sampling flow stability: ≤±5%

7.Sampling performance: Comply with the "BMRC" sampling efficiency curve

8.Power supply: Use Ni-H battery 2.3A/h, 6 cells, 4 current limiting resistors of 0.51Ω/10W in series, potted with epoxy resin and placed in the battery box, with a rated voltage Ue: 7.2V; its maximum output voltage Uo: 9.0V; maximum output current Io: 4.52A

9.Working voltage: 6.5V~9.0V DC (intrinsically safe)

10.Explosion-proof type: Intrinsically safe type for mining, explosion-proof mark: Exib I Mb

11.Dimensions: 218×160×80 (mm)

12.Weight: 2.50Kg
