Model:FT-V8A
Brand:tianyi
Audio And Video Life Detector Detailed Product Introduction and Technical Parameters
Audio And Video Life Detector is a life-saving detection device equipped with a video camera that can search for victims under collapsed buildings and confined spaces.
Audio And Video Life Detector Basic Configuration | ||
Implementation standards | Implement GB 4943.1-2011 "General Technical Specifications for Passive Metal Detection Doors" | Key parameters |
19.5mm diameter snake tube camera | ||
Screen Type | 5-inch true color LCD display | ☆☆☆ |
Pixels | 5 million: 3200(H)×800(V) | |
Infrared LED lights | 6 recording types | |
Audio sensor | 1 | |
Pickup range | 300 square meters | |
Lens | 0.5mm F1.2 120 ° | |
7-inch high-definition monitor | ||
Video Pixels (16:9) | HDMI:1920* 1080;1280*720 | |
Image format | JPG 5 million | |
Memory card | TF card 32GB | |
Audio | Speaker 1W; headphone frequency range: 20Hz-20KHz | |
interface | USB 2.0/AV-OUT | |
Voltage | DC :7-24V USB DC:5V |
