Temperature and Humidity Data Loggers

Temperature and Humidity Data Loggers are industrial wall-mounted high-protection casings, with IP65 protection, rain and snowproof and good breathability. The circuit uses imported industrial-grade microprocessor chips from the United States and imported high-precision temperature and humidity sensors to ensure excellent product reliability, high accuracy and interchangeability. The output signal type is RS485, and it can communicate up to 2000 meters. It is a standard modbus protocol and supports secondary development.

DC power supply (default) DC: 10-30V

Maximum power consumption: 0.4W

A accuracy

Humidity: ±2%RH (60%RH, 25℃)

Temperature: ±0.4℃ (25℃)

B accuracy (default)

Humidity: ±3%RH (60%RH, 25℃)

Temperature: ±0.5℃ (25℃)

Working temperature and humidity of the transmitter circuit: -20℃~+60℃, 0%RH~95%RH (non-condensing)

Probe working temperature: -40℃~+120℃ Default: -40℃~+80℃

Probe working humidity: 0%RH-100%RH

Communication Protocol: Modbus-RTU Communication Protocol

Output signal: 485 signal

Temperature display resolution: 0.1℃

Humidity display resolution: 0.1%RH

Temperature and humidity refresh time: 1s

Opening size: 70mm

Long-term stability: humidity ≤1%RH/y

Temperature ≤0.1℃/y

Response time: Humidity ≤8s (1m/s wind speed)

Temperature: ≤25s (1m/s wind speed)

Parameter settings: Set through software
