Radiation Sensor Solar Irradiance Sensor
Model：FT-FS4
Brand：tianyi
Radiation Sensor Solar Irradiance Sensor is a device that measures the amount of sunlight falling on a specific surface in a given period of time, determining the solar UV radiation value.
Get a Free Quote- Product details
- Related products
- Related articles
Radiation Sensor Solar Irradiance Sensor Product Introduction
Radiation Sensor Solar Irradiance Sensor is a device that measures the amount of sunlight falling on a specific surface in a given period of time, determining the solar UV radiation value.
Radiation Sensor Solar Irradiance Sensor Technical Indicators
Power supply: DC12V
Power consumption: 0.036W
Working environment: -20~65℃
Communication interface: RS485
Operating current: 3mA@DC12V
Minimum data interval: 0.5S
Radiation Sensor Solar Irradiance Sensor Sensor Parameters
| parameter | scope | Resolution | Accuracy | unit |
| Ultraviolet radiation | 0-500 | 0.01 | ＜±3% | W/m² |
Response time: ≤10S
Annual stability: ≤±3%
Zero point drift: ≤10 W/m²
Measured spectrum: 280-400nm
