FT-TS600 Automatic Soil Monitoring System: Enabling Precision Agriculture through Real-Time Data

The Automatic Soil Monitoring System is a common device in modern precision agriculture and ecological environment monitoring. It provides reliable data for farmland irrigation, drought warning, and scientific research by measuring key parameters such as soil moisture, temperature, and electrical conductivity in real time and continuously. The FT-TS600 Automatic Soil Monitoring System is a highly integrated, field-deployable automatic monitoring instrument in this category, featuring high precision, low power consumption, and multi-functional expandability.

The core functions of the device focus on monitoring three fundamental parameters: soil moisture content, soil temperature, and soil electrical conductivity. The moisture sensor has a measurement range of 0–100% with an accuracy of ±3%; the temperature measurement range covers -30°C to +70°C with an accuracy of ±0.3°C; and the electrical conductivity measurement range reaches 0–20,000 μS/cm, maintaining an accuracy of ±3% within the commonly used range.

The sensor is made of stainless steel, resistant to long-term electrolysis and corrosion, and can be deployed at different soil depths to achieve profile monitoring. Users can also expand the monitoring capabilities to include soil pH, air temperature and humidity, solar radiation, optical rainfall, and other meteorological elements based on actual needs, meeting comprehensive observation requirements for various scenarios.

The FT-TS600 is designed with a strong emphasis on reliability and convenience for field use. Its inlaid solar panel top cover not only improves photovoltaic conversion efficiency but also enhances the overall structure's wind resistance. The built-in MPPT charge controller automatically performs power point tracking to optimize charging efficiency. The device supports multiple data transmission methods, including wired, GPRS, and Bluetooth, and features an Android screen (optional) as a human-machine interface that operates stably in low-temperature environments. Combined with an SMS alarm function, it promptly notifies users when data exceeds limits, enabling unmanned operation and remote monitoring.

The monitoring system offers three data processing and access methods: PC standalone software, an Android APP, and a cloud platform. The PC software supports various communication protocols and provides flexible data storage, viewing, and analysis capabilities. The Android APP supports Bluetooth connectivity and continuous background data reception, with data export and chart display features. The cloud platform, based on a Client-Server architecture, supports multi-terminal login, real-time data dashboards, map positioning, threshold alarms, and data export and forwarding, meeting the needs of multi-user collaborative management and big data analysis.

In summary, the FT-TS600 Automatic Soil Monitoring System, with its high integration, easy deployment, multi-parameter monitoring, and full-platform support, is widely used in agriculture, forestry, geology, scientific research, education, and other fields. It is a practical tool for soil environment monitoring and rational water resource utilization.
