Locust online monitoring station

1.Product features of Locust online monitoring station

Locust online monitoring station remotely monitors the occurrence and damage of locusts by luring them and collecting photos.Locust online monitoring station is mainly suitable for locust breeding areas.It can collect and analyze and calculate information such as locust population density, age characteristics, etc.through light and sexual inducement.It supports time control functions, automatically take photos, and automatically identify common forest and grass locusts.It can collect and analyze the grassland locust information at fixed monitoring points, and send the data back to the monitoring and early warning center in real time.

2.Performance characteristics of Locust online monitoring station

1.Adopt stainless steel plastic-sprayed shell design.

2.Integrate light temptation, sexual temptation, machine vision, Internet of Things technology, and big data technology to realize online monitoring of locusts.

3.Through two methods, locust-specific attractant inducing and double-light inducing, double-light can be interchanged regularly.

4.It consists of a comprehensive control system, a 20 million high-definition photography system, and a insect body collection platform, which can clearly collect photos of locusts' stationary and moving states.

5.Supports time control function, automatic photography and automatic identification, and can identify common forest, grass, locusts.

6.Through data collection and analysis and calculation, the population density and age characteristics of locusts can be obtained.

7.Real-time monitoring and data alarm can be monitored remotely through the app or web client.

8.Equipped with a GPS positioning system, which can directly upload location information to the server.

9.Data transmission (3G/4G/5G) can be achieved through a variety of wireless networks, and the data supports local storage.

10.The overall design is adopted and can work normally on rainy days.

3.Technical parameters of Locust online monitoring station

1.Working voltage: DC12V

2.Double-light insect-induced light source: yellow light 580-620nm, red light wavelength 640-680nm

3.Solar panel power: ≥40W

4.Battery: DC12/20AH lithium battery

5.Power consumption: standby state ≤10W

6.Design life is ≥10 years
